IEEE JOURNAL ON SELECT AREAS IN COMMUNICATIONS, VOL. 16, NO. 8, OCTOBER 1998 1451 A Simple Transmit Diversity Technique for Wireless Communications Siavash M. Alamouti Abstract— This paper presents a simple two-branch transmit diversity scheme. Using two transmit antennas and one receive antenna the scheme provides the same diversity order as maximal-ratio receiver combining (MRRC) with one transmit antenna, and two receive antennas. It is also shown that the scheme may easily be generalized to two transmit antennas and M receive antennas to provide a diversity order of 2M. The new scheme does not require any bandwidth expansion any feedback from the receiver to the transmitter and its computation complexity is similar to MRRC. Index Terms—Antenna array processing, baseband processing, diversity, estimation and detection, fade mitigation, maximalratio combining, Rayleigh fading, smart antennas, space block coding, space–time coding, transmit diversity, wireless communications. I. INTRODUCTION THE NEXT-generation wireless systems are required to have high voice quality as compared to current cellular mobile radio standards and provide high bit rate data services (up to 2 Mbits/s). At the same time, the remote units are supposed to be small lightweight pocket communicators. Furthermore, they are to operate reliably in different types of environments: macro, micro, and picocellular; urban, suburban, and rural; indoor and outdoor. In other words, the next generation systems are supposed to have better quality and coverage, be more power and bandwidth efficient, and be deployed in diverse environments. Yet the services must remain affordable for widespread market acceptance. Inevitably, the new pocket communicators must remain relatively simple. Fortunately, however, the economy of scale may allow more complex base stations. In fact, it appears that base station complexity may be the only plausible trade space for achieving the requirements of next generation wireless systems. The fundamental phenomenon which makes reliable wireless transmission difficult is time-varying multipath fading [1]. It is this phenomenon which makes tetherless transmission a challenge when compared to fiber, coaxial cable, line-of-sight microwave or even satellite transmissions. Increasing the quality or reducing the effective error rate in a multipath fading channel is extremely difficult. In additive white Gaussian noise (AWGN), using typical modulation and coding schemes, reducing the effective bit error rate (BER) from 10 to 10 may require only 1- or 2-dB higher signalto-noise ratio (SNR). Achieving the same in a multipath fading Manuscript received September 1, 1997; revised February 1, 1998. The author was with AT&T Wireless Services, Redmond, WA, USA. He is currently with Cadence Design Systems, Alta Business Unit, Bellevue, WA 98005-3016 USA (e-mail: siavash@cadence.com). Publisher Item Identifier S 0733-8716(98)07885-8. environment, however, may require up to 10 dB improvement in SNR. The improvement in SNR may not be achieved by higher transmit power or additional bandwidth, as it is contrary to the requirements of next generation systems. It is therefore crucial to effectively combat or reduce the effect of fading at both the remote units and the base stations, without additional power or any sacrifice in bandwidth. Theoretically, the most effective technique to mitigate multipath fading in a wireless channel is transmitter power control. If channel conditions as experienced by the receiver on one side of the link are known at the transmitter on the other side, the transmitter can predistort the signal in order to overcome the effect of the channel at the receiver. There are two fundamental problems with this approach. The major problem is the required transmitter dynamic range. For the transmitter to overcome a certain level of fading, it must increase its power by that same level, which in most cases is not practical because of radiation power limitations and the size and cost of the amplifiers. The second problem is that the transmitter does not have any knowledge of the channel experienced by the receiver except in systems where the uplink (remote to base) and downlink (base to remote) transmissions are carried over the same frequency. Hence, the channel information has to be fed back from the receiver to the transmitter, which results in throughput degradation and considerable added complexity to both the transmitter and the receiver. Moreover, in some applications there may not be a link to feed back the channel information. Other effective techniques are time and frequency diversity. Time interleaving, together with error correction coding, can provide diversity improvement. The same holds for spread spectrum. However, time interleaving results in large delays when the channel is slowly varying. Equivalently, spread spectrum techniques are ineffective when the coherence bandwidth of the channel is larger than the spreading bandwidth or, equivalently, where there is relatively small delay spread in the channel. In most scattering environments, antenna diversity is a practical, effective and, hence, a widely applied technique for reducing the effect of multipath fading [1]. The classical approach is to use multiple antennas at the receiver and perform combining or selection and switching in order to improve the quality of the received signal. The major problem with using the receive diversity approach is the cost, size, and power of the remote units. The use of multiple antennas and radio frequency (RF) chains (or selection and switching circuits) makes the remote units larger and more expensive. As a result, diversity techniques have almost exclusively been 0733–8716/98$10.00  199 IEEE Authorized licensed use limited to: XIDIAN UNIVERSITY. Downloaded on April 21,2020 at 07:05:52 UTC from IEEE Xplore. Restrictions apply

1452 IEEE JOURNAL ON SELECT AREAS IN COMMUNICATIONS.VOL 16.NO.&OCTOBER 1998 as it effectively reduces the effect of fading at the r remote units using multiple transmit antennas at the base stations. Section II,the classical maximal ratio receive diversit ons rath remo this reasor bining n I th d simple mathen it d one antenna and one transmit chain may he added to a has mesith one and with two receive ant as are discussed station toimprove the reception qualityof all the remote nt In Section IV,the bit-error performance of the new scheme in that ase station's coverage area vith coherent D nary phase eceive co etical in Recently,some interesting approaches for transmit diversity tations of the pror posed scheme and the classical MRRC.These differences are discussed in detail in Section V Witt and Winters 5 for a single base station in which copeso the same symbol are transmitted through multiple antennas at different time likeli (MMSE) ualize is the used to resove multipath distortion and obtain diversity gain approach is space-time trellis coding airlink,and the receive chain may be modeled by a complex Another s are oded a d of a magnitud respons and are decoded using a maximum likelihood decoder This nna and the receive antenna zero is den scheme is very effective,as it combines the benefits of forward between the transmit antenna and the receive antenna one is denoted by h where ing and dive fo tiall ho = as a function of bandwidth efficiency (bits/s/HZ)and the h1=1cJ所 () Therefore,for some applications it ma prac diversity scheme which receiver on one ri=h1s0 +n 2 the opp The where no and n rep esen e an at the for thes scheme mav easily he generalized to two trar mit anten and order of 2M.Thisis signals is to choose signalif and only if (i) from the re d(ro.hosi)+d(ri.hisi)s d(ro.host) +d(r.h). 付≠k (3) across multiple antennas,not in time or frequency. where (x,y)is the squared Euclidean distance between he new can improve the ero signals and y calculated by the following expression: ms The de ow the P红，=(x-x*- (④ of higher level modulation schemes to in the effective data rate.or smaller reuse ors in a multice environment scheme for tw-branch MRC to inc system c. also be us other words.the new scheme is effective in all of the applica =hi(h tions here multipath fading +no)+hi(hiso+n) =(a6+ai)so+hono+hin1. her ve w the Expanding (3)and using(4)and(5)we get of exis quaity and to be a superb candidate for next-generation wireless systems. choose s iff (a后+a)s2-0-64 ≤(a哈+a跳P-0s-6跳， ∀i≠k(6) 12020t0 E-ERUTO IEEr

1452 IEEE JOURNAL ON SELECT AREAS IN COMMUNICATIONS, VOL. 16, NO. 8, OCTOBER 1998 applied to base stations to improve their reception quality. A base station often serves hundreds to thousands of remote units. It is therefore more economical to add equipment to base stations rather than the remote units. For this reason, transmit diversity schemes are very attractive. For instance, one antenna and one transmit chain may be added to a base station to improve the reception quality of all the remote units in that base station’s coverage area.1 The alternative is to add more antennas and receivers to all the remote units. The first solution is definitely more economical. Recently, some interesting approaches for transmit diversity have been suggested. A delay diversity scheme was proposed by Wittneben [2], [3] for base station simulcasting and later, independently, a similar scheme was suggested by Seshadri and Winters [4], [5] for a single base station in which copies of the same symbol are transmitted through multiple antennas at different times, hence creating an artificial multipath distortion. A maximum likelihood sequence estimator (MLSE) or a minimum mean squared error (MMSE) equalizer is then used to resolve multipath distortion and obtain diversity gain. Another interesting approach is space–time trellis coding, introduced in [6], where symbols are encoded according to the antennas through which they are simultaneously transmitted and are decoded using a maximum likelihood decoder. This scheme is very effective, as it combines the benefits of forward error correction (FEC) coding and diversity transmission to provide considerable performance gains. The cost for this scheme is additional processing, which increases exponentially as a function of bandwidth efficiency (bits/s/Hz) and the required diversity order. Therefore, for some applications it may not be practical or cost-effective. The technique proposed in this paper is a simple transmit diversity scheme which improves the signal quality at the receiver on one side of the link by simple processing across two transmit antennas on the opposite side. The obtained diversity order is equal to applying maximal-ratio receiver combining (MRRC) with two antennas at the receiver. The scheme may easily be generalized to two transmit antennas and receive antennas to provide a diversity order of . This is done without any feedback from the receiver to the transmitter and with small computation complexity. The scheme requires no bandwidth expansion, as redundancy is applied in space across multiple antennas, not in time or frequency. The new transmit diversity scheme can improve the error performance, data rate, or capacity of wireless communications systems. The decreased sensitivity to fading may allow the use of higher level modulation schemes to increase the effective data rate, or smaller reuse factors in a multicell environment to increase system capacity. The scheme may also be used to increase the range or the coverage area of wireless systems. In other words, the new scheme is effective in all of the applications where system capacity is limited by multipath fading and, hence, may be a simple and cost-effective way to address the market demands for quality and efficiency without a complete redesign of existing systems. Furthermore, the scheme seems to be a superb candidate for next-generation wireless systems, 1 In fact, many cellular base stations already have two receive antennas for receive diversity. The same antennas may be used for transmit diversity. as it effectively reduces the effect of fading at the remote units using multiple transmit antennas at the base stations. In Section II, the classical maximal ratio receive diversity combining is discussed and simple mathematical descriptions are given. In Section III, the new two-branch transmit diversity schemes with one and with two receive antennas are discussed. In Section IV, the bit-error performance of the new scheme with coherent binary phase-shift keying (BPSK) modulation is presented and is compared with MRRC. There are cost and performance differences between the practical implementations of the proposed scheme and the classical MRRC. These differences are discussed in detail in Section V. II. CLASSICAL MAXIMAL-RATIO RECEIVE COMBINING (MRRC) SCHEME Fig. 1 shows the baseband representation of the classical two-branch MRRC. At a given time, a signal is sent from the transmitter. The channel including the effects of the transmit chain, the airlink, and the receive chain may be modeled by a complex multiplicative distortion composed of a magnitude response and a phase response. The channel between the transmit antenna and the receive antenna zero is denoted by and between the transmit antenna and the receive antenna one is denoted by where (1) Noise and interference are added at the two receivers. The resulting received baseband signals are (2) where and represent complex noise and interference. Assuming and are Gaussian distributed, the maximum likelihood decision rule at the receiver for these received signals is to choose signal if and only if (iff) (3) where is the squared Euclidean distance between signals and calculated by the following expression: (4) The receiver combining scheme for two-branch MRRC is as follows: (5) Expanding (3) and using (4) and (5) we get choose iff (6) Authorized licensed use limited to: XIDIAN UNIVERSITY. Downloaded on April 21,2020 at 07:05:52 UTC from IEEE Xplore. Restrictions apply

1454 IEEE JOURNAL ON SELECT AREAS IN COMMUNICATIONS, VOL. 16, NO. 8, OCTOBER 1998 TABLE I THE ENCODING AND TRANSMISSION SEQUENCE FOR THE TWO-BRANCH TRANSMIT DIVERSITY SCHEME The channel at time may be modeled by a complex multiplicative distortion for transmit antenna zero and for transmit antenna one. Assuming that fading is constant across two consecutive symbols, we can write (10) where is the symbol duration. The received signals can then be expressed as (11) where and are the received signals at time and and and are complex random variables representing receiver noise and interference. 2) The Combining Scheme: The combiner shown in Fig. 2 builds the following two combined signals that are sent to the maximum likelihood detector: (12) It is important to note that this combining scheme is different from the MRRC in (5). Substituting (10) and (11) into (12) we get (13) 3) The Maximum Likelihood Decision Rule: These combined signals are then sent to the maximum likelihood detector which, for each of the signals and , uses the decision rule expressed in (7) or (9) for PSK signals. The resulting combined signals in (13) are equivalent to that obtained from two-branch MRRC in (5). The only difference is phase rotations on the noise components which do not degrade the effective SNR. Therefore, the resulting diversity order from the new two-branch transmit diversity scheme with one receiver is equal to that of two-branch MRRC. B. Two-Branch Transmit Diversity with Receivers There may be applications where a higher order of diversity is needed and multiple receive antennas at the remote units are feasible. In such cases, it is possible to provide a diversity order of 2 with two transmit and receive antennas. For illustration, we discuss the special case of two transmit and two receive antennas in detail. The generalization to receive antennas is trivial. Fig. 3. The new two-branch transmit diversity scheme with two receivers. TABLE II THE DEFINITION OF CHANNELS BETWEEN THE TRANSMIT AND RECEIVE ANTENNAS TABLE III THE NOTATION FOR THE RECEIVED SIGNALS AT THE TWO RECEIVE ANTENNAS Fig. 3 shows the baseband representation of the new scheme with two transmit and two receive antennas. The encoding and transmission sequence of the information symbols for this configuration is identical to the case of a single receiver, shown in Table I. Table II defines the channels between the transmit and receive antennas, and Table III defines the notation for the received signal at the two receive antennas. Where (14) , , , and are complex random variables representing receiver thermal noise and interference. The combiner in Fig. 3 builds the following two signals that are sent to the maximum Authorized licensed use limited to: XIDIAN UNIVERSITY. Downloaded on April 21,2020 at 07:05:52 UTC from IEEE Xplore. Restrictions apply

ALAMOUTI: SIMPLE TRANSMIT DIVERSITY TECHNIQUE FOR WIRELESS COMMUNICATIONS 1455 Fig. 4. The BER performance comparison of coherent BPSK with MRRC and two-branch transmit diversity in Rayleigh fading. likelihood detector: (15) Substituting the appropriate equations we have (16) These combined signals are then sent to the maximum likelihood decoder which for signal uses the decision criteria expressed in (17) or (18) for PSK signals. Choose iff (17) Choose iff (18) Similarly, for using the decision rule is to choose signal iff (19) or, for PSK signals, choose iff (20) The combined signals in (16) are equivalent to that of fourbranch MRRC, not shown in the paper. Therefore, the resulting diversity order from the new two-branch transmit diversity scheme with two receivers is equal to that of the four-branch MRRC scheme. It is interesting to note that the combined signals from the two receive antennas are the simple addition of the combined signals from each receive antenna, i.e., the combining scheme is identical to the case with a single receive antenna. We may hence conclude that, using two transmit and receive antennas, we can use the combiner for each receive antenna and then simply add the combined signals from all the receive antennas to obtain the same diversity order as -branch MRRC. In other words, using two antennas at the transmitter, the scheme doubles the diversity order of systems with one transmit and multiple receive antennas. An interesting configuration may be to employ two antennas at each side of the link, with a transmitter and receiver chain connected to each antenna to obtain a diversity order of four at both sides of the link. IV. ERROR PERFORMANCE SIMULATIONS The diversity gain is a function of many parameters, including the modulation scheme and FEC coding. Fig. 4 shows the BER performance of uncoded coherent BPSK for MRRC and the new transmit diversity scheme in Rayleigh fading. It is assumed that the total transmit power from the two antennas for the new scheme is the same as the transmit power from the single transmit antenna for MRRC. It is also assumed that the amplitudes of fading from each transmit antenna to each receive antenna are mutually uncorrelated Rayleigh distributed and that the average signal powers at each receive antenna from each transmit antenna are the same. Further, we assume that the receiver has perfect knowledge of the channel. Although the assumptions in the simulations may seem highly unrealistic, they provide reference performance curves for comparison with known techniques. An important issue is Authorized licensed use limited to: XIDIAN UNIVERSITY. Downloaded on April 21,2020 at 07:05:52 UTC from IEEE Xplore. Restrictions apply
